TUI : heimdall or tui

Running heimdall without any command (or heimdall tui, heimdall ui) opens a full screen interface to navigate through your git repositories, see their state and run actions on one or several of them.

heimdall -w ~/work

The list shows the repositories found in the work directory as the tree of the folders they are in, like a file navigator : each folder lists its folders, then its repositories, the ones needing attention first. A folder holding nothing but another folder shares its line with it. Next to it are the details of the current repository : what state it is in and what you can do about it, the output of the last commands run on it, its changed files, its incoming and not pushed commits, its branches and its last commits.

On a terminal less than 80 columns wide, the list and the details are displayed one at a time : Tab goes from one to the other.

Reading the list

Above the list, the header tells how many repositories are in each state, and the colored band below it shows the share of each of them, the most urgent on the left. On the right is the directory Heimdall is looking in or, while actions are running, how many of them are done.

Each repository is listed with the branch it is on, when there is room for it, and its state.

The state of each repository is written in plain words on its right, in a color telling how urgent it is.

Color	State
Red	Diverged from origin, or the repository can't be read
Orange	Behind origin
Yellow	Local changes
Teal	Commits not pushed
Green	Up to date
Grey	Nothing to do, but it can't be told to be up to date : no remote, branch not on origin, or last fetch more than a day old

While an action is running on a repository, its state is replaced by what is being done. Then the result of the action is displayed instead, until the next one.

No network at startup

To be displayed quickly, the list is built from local information only, so what it knows about origin dates from the last fetch. When this fetch is more than a day old, the details tell its age : press F to check origin.

The other commands (git-info, git-clone, good-morning, env-info) are still available for a non-interactive usage.

Navigation

Key	Action
Up / Down or J / K	Move
G / Shift+G or Home / End	First / last repository
Page Up / Page Down	Previous / next page
Tab	Go to the details, Tab again to go back
Enter	Collapse / expand the folder
Left or H	Collapse the folder, or go to the folder the line is in
Right or L	Expand the folder, or go into it
Z	Collapse / expand all the folders
/	Filter repositories by path
Esc	Clear the filter, then the selection
?	Help
Q	Quit

Selection

Actions are run on the selected repositories or, if none is selected, on the current one. With the cursor on a folder, they are run on all its repositories, the ones of the folders it holds included.

A collapsed folder tells what its repositories need, and the details list them all by state, the ones needing attention first. When the list is scrolled, its first line tells the whole path of the folder the next ones are in.

Key	Action
Space	Select / unselect the current repository, or all the ones of the current folder
A	Select / unselect all the displayed repositories
U	Select the repositories which can be pulled

Actions

A confirmation is asked before pulling or running commands on several repositories.

Key	Action
R	Refresh local status
F	git fetch
P	git pull, skipped for repositories with local changes
M	Run the morning routine defined in the configuration file
!	Run a command

Branches

When a repository has several local branches, the details list them : the one the repository is on first, marked with a star, then the most recently committed ones. Each tells where it stands compared to origin and how old its last commit is, so that work left on a branch which was never pushed is not forgotten.

Press Tab to go to the details, then :

Key	Action
Up / Down or J / K	Choose a branch, or scroll the details when there is only one
Enter	Switch to the chosen branch with git switch
Page Up / Page Down	Scroll the details
Tab or Esc	Go back to the list

When git refuses to switch, because of local changes for instance, the details tell why.

Available options

Search depth: --depth or -d

By default, it searches no more than 3 levels of subdirectories, you can override this with the -d flag of the tui command.

heimdall tui -d 5

Global flags

The global flags are available too. With --no-color, the states are told by their text only and the colored band is not displayed.
